8,13 € z VAT
Szt.
Właściwości
size Standard
Nominal width [mm] 2,3
installation position arbitrary
Packing size 10
Construction set up Push-pull principle
Operating pressure complete temperature range [bar] -0.95 to 6
Temperature depending operating pressure [bar] -0.95 to 14
Maritime classification see Certificate
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-],
Water according to manufacturer declaration at www.festo.com
Information about operating and control medium Oiled operation possible
Corrosion resistant class KBK 1 - low corrosion stress
ambient temperature [°C] -10 to 80
Pneumatic connection 1 For hose exterior diameter 8 mm
Pneumatic connection 2 For hose exterior diameter 4 mm
Sleeve colour blue
Material information RoHs compliant
Housing material PBT
Sleeve material POM
Tube seal, hose seal material NBR
Hose clamping segment material High-alloyed stainless steels
Number of outlets 2
Number of supply lines 1
Więcej informacji OT-FESTO015576
Ciężar 14 g / Szt.
GTIN 4052568023713
Jednostka opakowania 10 Szt.
Numer towaru podlegającego ocleniu 39174000
Producent Festo
Dokumenty


Podawane informacje są niezobowiązującymi danymi orientacyjnymi! Nie ponosimy odpowiedzialności za dane wybrane bez pisemnego potwierdzenia. Dane ciśnienia dotyczą, o ile nie podano inaczej, płynów z grupy II w temperaturze +20°C.
