Data sheet
Bimetallic thermometer, vert-ical D160/0 to +60°C/200mm
Item number:
TS 60160200
Example illustration
Item description
Application:
Industrial manometer for use in mechanical engineering, tank construction, pipeline construction and heating technology. Also suitable for aggressive materials to be measured.
Materials:
Housing: 1.4301, stem: 1.4571, window: instrument plate glass
Display correction:
Adjustable indicator
Protection class:
IP 43
Protective tube connection:
G 1/2" (thermowell model B)
Dip shaft Ø:
8 mm
Class:
1
Temperature range:
Environment: -20 to +60 °C
Operating pressure at the stem:
max. 25 bar
Note:
WIKA Type R52
Properties
| Diameter [mm] | 160 |
| Display range [°C] | 0 to +60 |
| Stem length L [mm] | 200 |
| Scale division [K] | 1 |
| F [mm] | 96 |
| H [mm] | 42,5 |
Further information:
| Weight | 600 g / pcs |
| GTIN | 4050571705367 |
| Customs duty number | 90251900 |
| RoHS compliant | Yes |
| Manufacturer | WIKA (WEEE DE92770372) |
Drawing:
Drawing: Bimetal thermometer vertical without thermowell, industrial version
More information on this item and the process for ordering it can be found in our online shop https://www.landefeld.de under item number TS 60160200.
Landefeld Druckluft und Hydraulik GmbH · Konrad-Zuse-Straße 1 · 34123 Kassel · Germany
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
As of: 26.04.2025
