Item group
1 SN - one steel mesh, EN 853
YouTube videos:
Materials:
Inner core: synthetic rubber, outer cover: synthetic rubber, ozone and weather resistant, pressure carrier: one or two steel wire braids
Media:
Hydraulic oils on basis of mineral oil, air**, vacuum*** (max. -0,83 bar according to SAE 100 R4), water, lubricants and fuels
Operating range:
high pressure hydraulic systems
Delivered as:
Due to the manufacturing process, we cannot exclude that the goods are delivered in parts. We try to deliver a maximum of 3 sections smaller than 20 m. and none of the sections is shorter than 3 m.
Temperature range:
-40 to +100 °C (temporarily +125 °C)
**Hose must be crimped, ***1 SN 38 & 1 SN 51 not suitable for vacuum
Documents:
More information
1 SN - one steel mesh, EN 853:
10 of 10 articles
1 SN 6
1 SN hose, EN 853, DN 6
€19.56
incl. VAT
1 SN 8
1 SN hose, EN 853, DN 8
€21.28
incl. VAT
1 SN 10
1 SN hose, EN 853, DN 10
€22.32
incl. VAT
1 SN 12
1 SN hose, EN 853, DN 12
€26.54
incl. VAT
1 SN 16
1 SN hose, EN 853, DN 16
€32.57
incl. VAT
1 SN 19
1 SN hose, EN 853, DN 19
€35.88
incl. VAT
1 SN 25
1 SN hose, EN 853, DN 25
€61.45
incl. VAT
1 SN 31
1 SN hose, EN 853, DN 31
€71.52
incl. VAT
1 SN 38
1 SN hose, EN 853, DN 38
€90.34
incl. VAT
1 SN 51
1 SN hose, EN 853, DN 51
€103.85
incl. VAT
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
