Item group

Pressure limiting valves for inline assembly, up to 150 l/min

Suitable:

The valves restrict the system pressure and are ideal for overpressure protection as well as for continuous operation.

Materials:

Body: Aluminium, screw-in valve: zinc plated steel, seal: NBR

Temperature range:

-20 to +80 °C

Media:

Hydraulic oils on the basis of mineral oil
*minimum pressure regulation range determined at 5 l/min

Documents:

More information Less information

Filter items

Débit nominal [l/min]
Please select
Filetage
Please select
Plage de régulation de la pression*. [bar]
Please select
exécution
Please select
Pressure limiting valves for inline assembly, up to 150 l/min:
20 of 24 articles
pressure limiting valve 3x G 3/8", 5 to 50 bar, max. 30 l/min(DBV38P50Q30)
DBV38P50Q30
pressure limiting valve 3x G 3/8", 5 to 50 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 3/8", 30 to 100 bar, max. 30 l/min(DBV38P100Q30)
DBV38P100Q30
pressure limiting valve 3x G 3/8", 30 to 100 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 3/8", 50 to 210 bar, max. 30 l/min(DBV38P210Q30)
DBV38P210Q30
pressure limiting valve 3x G 3/8", 50 to 210 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 3/8", 100 to 350 bar, max. 30 l/min(DBV38P350Q30)
DBV38P350Q30
pressure limiting valve 3x G 3/8", 100 to 350 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 1/2", 5 to 50 bar, max. 30 l/min(DBV12P50Q30)
DBV12P50Q30
pressure limiting valve 3x G 1/2", 5 to 50 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 1/2", 30 to 100 bar, max. 30 l/min(DBV12P100Q30)
DBV12P100Q30
pressure limiting valve 3x G 1/2", 30 to 100 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 1/2", 50 to 210 bar, max. 30 l/min(DBV12P210Q30)
DBV12P210Q30
pressure limiting valve 3x G 1/2", 50 to 210 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 1/2", 100 to 350 bar, max. 30 l/min(DBV12P350Q30)
DBV12P350Q30
pressure limiting valve 3x G 1/2", 100 to 350 bar, max. 30 l/min
€111.48 incl. VAT
Immediately available
pressure limiting valve 3x G 1/2", 5 to 50 bar, max. 80 l/min(DBV12P50Q80)
DBV12P50Q80
pressure limiting valve 3x G 1/2", 5 to 50 bar, max. 80 l/min
€147.10 incl. VAT
Immediately available
pressure limiting valve 3x G 1/2", 30 to 100 bar, max. 80 l/min(DBV12P100Q80)
DBV12P100Q80
pressure limiting valve 3x G 1/2", 30 to 100 bar, max. 80 l/min
€147.10 incl. VAT
Immediately available
pressure limiting valve 3x G 1/2", 80 to 250 bar, max. 80 l/min(DBV12P250Q80)
DBV12P250Q80
pressure limiting valve 3x G 1/2", 80 to 250 bar, max. 80 l/min
€147.10 incl. VAT
Immediately available
pressure limiting valve 3x G 3/4", 5 to 50 bar, max. 80 l/min(DBV34P50Q80)
DBV34P50Q80
pressure limiting valve 3x G 3/4", 5 to 50 bar, max. 80 l/min
€147.10 incl. VAT
Immediately available
pressure limiting valve 3x G 3/4", 30 to 100 bar, max. 80 l/min(DBV34P100Q80)
DBV34P100Q80
pressure limiting valve 3x G 3/4", 30 to 100 bar, max. 80 l/min
€137.60 incl. VAT
Immediately available
pressure limiting valve 3x G 3/4", 80 to 350 bar, max. 80 l/min(DBV34P250Q80)
DBV34P250Q80
pressure limiting valve 3x G 3/4", 80 to 350 bar, max. 80 l/min
€147.10 incl. VAT
Immediately available
pressure limiting valve 2x G 1/2", 3 to 70 bar, max. 150 l/min(DBV12P70Q150)
DBV12P70Q150
pressure limiting valve 2x G 1/2", 3 to 70 bar, max. 150 l/min
€268.30 incl. VAT
deliverable again in ⌀ 8 days
pressure limiting valve 2x G 1/2", 7 to 105 bar, max. 150 l/min(DBV12P105Q150)
DBV12P105Q150
pressure limiting valve 2x G 1/2", 7 to 105 bar, max. 150 l/min
€268.30 incl. VAT
Immediately available
pressure limiting valve 2x G 1/2", 10 to 210 bar, max. 150 l/min(DBV12P210Q150)
DBV12P210Q150
pressure limiting valve 2x G 1/2", 10 to 210 bar, max. 150 l/min
€268.30 incl. VAT
Immediately available
pressure limiting valve 2x G 1/2", 35 to 350 bar, max. 150 l/min(DBV12P350Q150)
DBV12P350Q150
pressure limiting valve 2x G 1/2", 35 to 350 bar, max. 150 l/min
€268.30 incl. VAT
Immediately available
pressure limiting valve 2x G 3/4", 3 to 70 bar, max. 150 l/min(DBV34P70Q150)
DBV34P70Q150
pressure limiting valve 2x G 3/4", 3 to 70 bar, max. 150 l/min
€268.30 incl. VAT
Immediately available
pressure limiting valve 2x G 3/4", 7 to 105 bar, max. 150 l/min(DBV34P105Q150)
DBV34P105Q150
pressure limiting valve 2x G 3/4", 7 to 105 bar, max. 150 l/min
€268.30 incl. VAT
Immediately available
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
