Skupina artiklov
Storz prehodni kosi
Materials:
Seal: NBR (stainless steel: FKM)
Temperature range:
-40°C to max. +110°C (Stainless steel: -15°C to max. +200°C)
Operating pressure:
max. 16 bar
Operating range:
Industry, fire brigade, refinery, agriculture, construction industry, maritime, military and catastrophe protection
Dimensions for determining the size of Storz couplings DIN sizes
lug distance 31 mm = Storz size 25-D, lug distance 66 mm = Storz size 52-C, lug distance 89 mm = Storz size 75-B, lug distance 133 mm = Storz size 110-A
Advantages:
•simple assignment of hose end and connection,
•fast connection and disconnection through a 120°-rotation,
•All couplings with the same lug distance are compatible with one another. The rule that applies is: same lug distance, same nominal size,
•large range of applications through the use of application-specific hoses,
•Aluminium forged - no danger of breakage, such as exists with cast couplings of aluminium,
•Brass - body is made of DVGW/KTW-compliant alloy.
•fast connection and disconnection through a 120°-rotation,
•All couplings with the same lug distance are compatible with one another. The rule that applies is: same lug distance, same nominal size,
•large range of applications through the use of application-specific hoses,
•Aluminium forged - no danger of breakage, such as exists with cast couplings of aluminium,
•Brass - body is made of DVGW/KTW-compliant alloy.
Dokumenti:
Več informacij
Filtriraj artikle
več filtrov
Storz prehodni kosi:
20 od 23 izdelkov
STK 51/31 A
Storz connector 38 / 25-D, Aluminij (kovan)
124,27 €
z DDV
STK 66/31 A
Storz connector 52-C / 25-D, Aluminij (kovan)
55,48 €
z DDV
STK 81/51 A
Storz connector 65 / 38, Aluminij (kovan)
151,69 €
z DDV
STK 81/66 A
Storz connector 65 / 52-C, Aluminij (kovan)
76,24 €
z DDV
STK 89/66 A
Storz connector 75-B / 52-C, Aluminij (kovan)
65,08 €
z DDV
STK 89/81 A
Storz connector 75-B / 65, Aluminij (kovan)
97,22 €
z DDV
STK 105/89 A
Storz connector 90 / 75-B, Aluminij (kovan)
180,48 €
z DDV
STK 115/89 A
Storz connector 100 / 75-B, Aluminij (kovan)
180,48 €
z DDV
STK 115/105 A
Storz connector 100 / 90, Aluminij (kovan)
395,45 €
z DDV
STK 133/89 A
Storz connector 110-A / 75-B, Aluminij (kovan)
130,52 €
z DDV
STK 133/115 A
Storz connector 110-A / 100, Aluminij (kovan)
219,89 €
z DDV
STK 66/31 MS
Storz connector 52-C / 25-D, Medenina
178,24 €
z DDV
STK 81/66 MS
Storz connector 65 / 52-C, Medenina
273,35 €
z DDV
STK 89/66 MS
Storz connector 75-B / 52-C, Medenina
221,22 €
z DDV
STK 89/81 MS
Storz connector 75-B / 65, Medenina
337,28 €
z DDV
Ni na zalogi
STK 133/89 MS
Storz connector 110-A / 75-B, Medenina
774,87 €
z DDV
STK 66/31 ES
Storz connector 52-C / 25-D, 1.4581
579,65 €
z DDV
STK 81/66 ES
Storz connector 65 / 52-C, 1.4581
739,39 €
z DDV
STK 89/66 ES
Storz connector 75-B / 52-C, 1.4581
650,62 €
z DDV
STK 89/81 ES
Storz connector 75-B / 65, 1.4581
857,92 €
z DDV
Vse navedbe podatkov so nezavezujoče orientacijske vrednosti! Za izbiro podatkov, za katere ne izdamo pisnega potrdila, ne prevzemamo jamstev. Navedbe tlaka, v kolikor ni navedeno drugače, se nanašajo na tekočine skupine II. pri +20°C.
